BAS 156
Rhine bridge new Kamp
© Frank Sellke / brueckenweb.de
Use in accordance with the terms and conditions
17.12.2023
© www.brueckenweb.de / Frank Sellke
Use in accordance with the terms and conditions
auf dem Mittelstreifen
06.10.2010
© Frank Sellke / brueckenweb.de
Use in accordance with the terms and conditionsGermany
North Rhine-Westphalia
Duisburg
Rhine Dezember 778.3
Rhine
Motorway A40
Cable-stayed bridge
Steel
1966-1970 (eröffnet am 15.10.1970)
350.00 m
777.40 m
35.80 m
50.00 m
0.00 m
27800.00 m2
in operation
Pylon height 50 m above the pillars<bR>Information from www.duisburg.de:<br><b>Bridge construction</b> <br><br>

<b>Bridge</b> <br>Steel central cable-stayed bridge with two pylons standing in the median strip to<br><br>

<b>Cross section</b> <br>zweizelliger steel box girder with orthotropher deck<br><br>

<b>Pylons</b> <br>two walk-in steel pylons with a height of about 50 metres on the roadways<br><br>
<b>Inclined ropes</b> <br>12 Rope groups 108 ropes with a total length of about 22.7 km. Each rope group has 9 ropes which have a diameter of 57 mm to 83 mm<br><br>
<hr>Rehabilitation of the bridge between August 2004 and December 2006 for 7 million euros
