BAS 159
Beeckerwerth Rhine Bridge A42 (Baerl)

© Frank Sellke / brueckenweb.de

© Frank Sellke / brueckenweb.de

11.05.2024
© www.brueckenweb.de / Frank Sellke
Germany
North Rhine-Westphalia
Duisburg
Rhine - km 785.3 North Duisburg
Rhine
A42 motorway
Cable-stayed bridge
Steel - Concrete
1990
310.00 m
1012.00 m
40.45 m
0.00 m
0.00 m
24674.00 m2
in operation
Planning approval decision: June 24, 1980
Confirmation by the Higher Administrative Court of Münster: 1985
Planning approval becomes legally binding: June 23, 1986
Contract awarded: July 1, 1986
Construction start of the flood relief bridge on the left bank of the Rhine: 1986
Construction start of the flood relief bridge on the right bank of the Rhine: February 1988
Start of work on the main bridge section (left bank of the Rhine): February 1988
Start of work on the power bridge section (right bank of the Rhine): February 1989
Last weld: February 1990
Completion was in October 1990
AS Krefeld
4506907
