Wörner Pier (Palace bridge)
14.10.2007
© Frank Sellke / brueckenweb.de
Use in accordance with the terms and conditions
14.10.2007
© Frank Sellke / brueckenweb.de
Use in accordance with the terms and conditions
14.10.2007
© Frank Sellke / brueckenweb.de
Use in accordance with the terms and conditionsGermany
Hesse
Darmstadt
Castle moat
Pedestrian
Girder bridge
Larch wood, Plexiglas, steel
2007
15.20 m
26.00 m
4.10 m
0.00 m
0.00 m
0.00 m2
in operation
Installation superstructure on September 22, 2007, opening on October 12, 2007<br><br>Length: approx. 26 m<br>Width: 4.10 m<br>Height: up to 3 metres<br>Height of the bridge over the moat: maximum 3 meters<br>Total weight of bridge: about 28 tons<br>Distance of the two supports: 15.20 m<br>The actual Laufsteges width: 1.60 m<br>Accepted traffic load: 5 kN / m m² (500 kg / m²)<br>Construction type of the main carrier: composite beams in wood and PLEXIGLAS ®<br>Wood cross section (top and bottom): each 2 x 15/20 cm<br>Thickness of the PLEXIGLAS ® discs: 70 mm<br>Dimensions PLEXIGLAS ® discs: up to 8 x 3 m<br>Total weight PLEXIGLAS ®: 11 t<br><br><br>In 2009 discovered a crack in a non-load bearing area of the sheet of plexiglass.
