BAS 4433
Highway overpass about A3
16.08.2002
© Frank Sellke / brueckenweb.de
Use in accordance with the terms and conditions
06.10.2024
© www.brueckenweb.de / Frank Sellke
Use in accordance with the terms and conditions
05.04.2008
© Frank Sellke / brueckenweb.de
Use in accordance with the terms and conditionsGermany
North Rhine-Westphalia
Duisburg
Motorway A3
Pedestrian
Beam bridge and Cove carrier
Steel
1936
44.00 m
94.00 m
6.00 m
0.00 m
0.00 m
0.00 m2
in operation
Information about this bridge from the book "German steel construction" (1937)<br>
<br>Year of construction: 1936<br>Steel weight: 124 t<br>Spans: 40 m (railway) + 10 m (dam between) Railway and Highway) + 44 m (motorway A3)
Main carrier sheet metal baffles: 1, 2 m in Center opening, 2. 8 m between pillar<br>Bridge width betw. Railings: 6m<br>Fully welded superstructure<br>
<br>With the widening of the A3, this bridge could remain because it had the required passage width left and right (and thus exposed, the pillar) after removal of the dams.
